AT-MC10x Series Media Converters Installation Guide
11
Network Topologies
The AT-MC10x Series Media Converters can be used in two different
types of topologies: standalone and back-to-back. Both topologies are
described below.
Standalone Topology
Figure 9 illustrates a standalone topology where two AT-8524M switches
have been interconnected with an AT-MC102XL media converter.
Figure 9. Standalone Topology
Cable Legend
100 Mbps
100 Mbps (Fiber)
757
LINK TST
M/L
ON
4
100Base-FX
LINK
ACT
100Base-TX
FDX
LINK
ACT M/L ON
PWR
TX RX
CLASS 1
LASER PRODUCT
AT-MC102XL
FAST ETHERNET MEDIA CONVERTER
A/N OFF
A/N ON
AT-8524M
AT-8524M
AT-MC102XL
