Appendix B: Cleaning Fiber Optic Connectors
40
Note
Do not touch the end face of the ferrule in the connector.
Warning
Do not stare into the laser beam. 2
Warning
Do not look directly at the fiber optic cable ends or inspect the cable ends
with an optical lens. 31
Using a Swab
Specially treated swabs, or stick cleaners, are available for cleaning
inside connector adapters or hard-to-reach ferrule tips. These swabs,
often referred to as “lint free” or “alcohol free” swabs, shown in Figure 26
on page 40, are available from many vendors. Stick cleaners are
available in both 2.5 mm and 1.25 mm sizes for use on SC and MU
connectors respectively.
Figure 26. Lint-Free and Alcohol-Free Swabs
Note
Never use a household cotton swab and alcohol to clean a fiber
optic connector. This may leave a residue on the ferrule tip.
Note
Do not used compressed air or aerosol air to clean a fiber optic
connector.
