Allied Telesis CentreCOM GS970M Series Quick Installation Guide

2 CentreCOM GS970M Series Quick Installation Guide
Introduction
This guide contains a short version of the installation instructions for
the GS970M Series of Gigabit Ethernet Switches. For more
instructions, refer to the GS970M Series of Gigabit Ethernet Switches
Installation Guide on the Allied Telesis web site at
www.alliedtelesis.com/us/en/services-support. This guide
contains the following sections:
 “Front Panels” next
 “PoE+ Power Budgets” on page 4
 “Beginning the Installation” on page 5
 “Installing the Switch” on page 9
 “Ports” on page 13
 “Powering On the Switch” on page 15
 “LEDs” on page 16
 “Starting a Local Management Session” on page 19
 “Troubleshooting” on page 20
Front Panels
The front panels of the switches are illustrated here.
GS970M/10
GS970M/10PS
6
7
3
1
2
5
7
3
1
2
5
7
2
3
1
GS970M/18
4
4
4
