Whenthefunctionisdisabled,operationinprimarymoderesumes,controlled

byshiftselector1.

USES:Foroilelddual-modevehicleswhicharedrivenon-roadinprimary

mode,thenusesecondarymodeforstationaryoileldoperationssuchas

pumping,swabbing,orwinching.

CUSTOMERMODIFIABLECONSTANTS:

None

VOCATIONS:Oileldpumper,cementer,winch

FUNCTIONRESPONSETOTCMPOWERINTERRUPTION(power-off,

followedbypowerrestored):

Poweroff:Nochange

Powerrestored:Nochange
