10 / 16 6-1624982 - rev.1 - 20/05/2021
ENG
5.3 ADVICE ON INSTALLATION
WHAT YOU CAN DO:
• Ensure that the motor is installed on level.
• The motor shall be installed at least 50 mm from the lower edge of the gate door.
• The motor can be installed at the top of the gate door.
• The motor can be installed on both left and right.
• The motor can be installed with the body facing downwards or upwards depending on your needs.
WHAT NOT TO DO:
• Do not install on sloping gates.
• Do not unduly bend the motor cable.
• Do not install the bracket in the gate in weak points that may break.
5.4 MOTOR UNLOCK FOR MANUAL MOVEMENT
To move the gate manually proceed as follows:
• Turn the key clockwise to unlock the lever.
• Pull the lever all the way down.
Once the gate is positioned to re-lock the motor:
• Completely put the lever back inside its seat in the motor
body.
• Hold the lever in place with one hand.
• Close the lever lock by turning the key counterclockwise.
