Alltrax SR48300 User Manual

7
http://www.alltraxinc.com
SR SPECIFICATIONS
Note
1
:
The larger number represents the value when the “Peak Amp Mode” is enabled in the Alltrax Toolkit
program.
All ratings are at 25°C with nominal rated voltages at 50% PWM. Actual currents are
±5% listed rating
Model Peak (Amps) 2 Min
(Amps)
5 Min
(Amps)
Continuous
(Amps)
SR48300 300/350
1
300 (1.5min) 230 125
SR48400 400/460
1
400 300 140
SR48500 500/575
1
500 350 175
SR48600 600/690
1
600 425 210
SR72300 300/350
1
300 275 130
SR72400 400/460
1
400 (1.5min) 300 150
SR72500 500/575
1
500 400 210
Type: Series Motor Controller
Operating Frequency: 18kHz
Controller Voltage, KSI & Reverse:
SR48XXX 12-48V nom, 62V max
SR72XXX 12-72V nom, 90V max
Controller Operating Temp: -20°C to 75°C, shutdown @ 85°C
Environmental Operating Temp: -20°C to 50°C
Stand by Power (Power up): <1W nom, <8W Fan on
Stand by Current: <20mA
Relay Drive Current: 5A peak, 1A Cont.
KSI Peak In Rush: 60V = 9A, 30V = 4A, 9.5V = 2A
Throttles Supported: 0-5k, 5k-0, E-Z-GO ITS, Club Cart 5k-0 3
Wire (MCOR), 0-5v, Taylor Dunn 6v-10.5v,
USB Throttle, Absolute Mode
Terminal Torque: Torque to 60-80 in.lb (5-7 ft/lb, 6.77-9.4Nm)
Mounting Bolt Torque: Torque bolts to 15-20 in.lb (1.25-
1.75 ft.lb, 1.7-2.25nm)
