Alltrax SR48500 User Manual

30
SR OPERATORS MANUAL
Error Code Denitions:
• Short Circuit/Output Fault:
Controller detected a short circuit or other fault on the output circuit.
Check wiring.
• Battery Under Voltage:
B+ Voltage lower than Low Voltage Battery Setting. Check pack
voltage or program settings.
• Battery Over Voltage:
B+ Voltage Higher than Over Voltage Battery Setting. Check pack
voltage or program settings
• Over temperature:
Busbar temperature exceeds 85
o
C. Let controller cool and/or add fan.
• Motor Field Failure:
 Controllerdetectedashortintheeldcircuit.Checkmotorresistance 
 andorreplaceeldwires.
• Pre-charge Failure:
B+ voltage and KSI voltage differ by more than 5v. Stuck solenoid.
• Under Temp:
Busbar Temperature reads less than -20
o
C
• High Throttle Over range & High Throttle Under range:
High Side of throttle signal is outside of acceptable window for that
throttle type. Check and/or replace throttle. Change throttle type to
correct throttle installed on car.
• Low Throttle Over range & Low Throttle Under range:
Low Side of throttle signal is outside of acceptable window for that
throttle type. Check and/or replace throttle. Change throttle type to
correct throttle installed on car.
• Uncalibrated throttle:
Throttle boundaries not found. In Toolkit program, select another
throttle then re-select correct throttle type.
• Bad Variable Set Loaded:
Alltrax loaded variable data is missing or corrupted. Contact Alltrax.
