Alltrax SR48500 User Manual

29
http://www.alltraxinc.com
The throttle code blinks on controller power up and alarm codes blink when
the alarm happens. All alarms are self clearing so when the alarm event is over,
the controller resumes normal operation, except for the Short Circuit alarm that
needs a power off cycle to clear the alarm.
Throttle codes:
1 Green LED Flash = 0-5k throttle
2 Green LED Flash = 5K-0 throttle
3 Green LED Flash = 0-5V throttle
4 Green LED Flash = EZGO ITS throttle
5 Green LED Flash = 0-1k Yamaha throttle
6 Green LED Flash = 6 to 10.5 Taylor Dunn throttle
7 Green LED Flash = Club Car 5k-0 3 wire throttle
8 Green LED Flash = Reserved
9 Green LED Flash = Pump
10 Green LED Flash = USB Throttle
11 Green LED Flash = Absolute Throttle
Normal Display Status:
Solid Green Light = Controller Ready to Run
Solid Red Light = Controller in programming mode
Solid Yellow Light = Throttle is wide open and the controller is
NOT in Current Limit
Blinking Yellow Light = Throttle is wide open, but the controller is in
Current Limit
Error Codes:
SR error codes are different than the AXE/DCX alarm codes in that they will
ashGreenandRed,insteadofjustRed.
1 Green and 1 Red LED Flash = Short Circuit
1 Green and 2 Red LED Flash = Battery Under Voltage
1 Green and 3 Red LED Flash = Battery Over Voltage
1 Green and 4 Red LED Flash = M- Over temperature
1 Green and 5 Red LED Flash = Bus Bar Over temperature
1 Green and 6 Red LED Flash = Pre-charge Failure
2 Green and 1 Red LED Flash = Under Temp
2 Green and 2 Red LED Flash = Not Used
2 Green and 3 Red LED Flash = High Throttle Over range
2 Green and 4 Red LED Flash = High Throttle Under range
2 Green and 5 Red LED Flash = Low Throttle Over range
2 Green and 6 Red LED Flash = Low Throttle Under range
3 Green and 1 Red LED Flash = Uncalibrated throttle
3 Green and 2 Red LED Flash = Bad Variable Set Loaded
BLINK CODES
