Progressing Cavity Pumps
Dismounting (7.2.1 Series AE)
•Dismount tie rods, discharge casing, stator
•Dismount suction casing
•Dismount joints
•Dismount drive shaft and the mech. seal
•Dismount the bearing
Rotor Pin type joint Drive shaft
Stator Coupling rod Bearing bracket
