Almatec A 25 - Spare Part List (EEE - ETZ)

10
Spare part list ALMATEC A-Series, EEE – ETZ
Material housing parts: Polyethylene (PE)
Pump size A 15 E… A 25 E.. A 40 E.. A 50 E..
Item Pc. Description Material Part-No. Part-No. Part-No. Part-No.
1 2 Side housing PE 2 15 010 51 2 25 010 51 2 40 010 51 2 50 010 51
2 1 Center housing PE 2 15 011 51 2 25 011 51 2 40 011 51 2 50 011 51
3 4 Sleeve PE 2 15 012 51 2 25 012 51 2 40 012 51 2 50 012 51
4 2 Valve stop, suction valve PE 2 15 013 51 2 25 013 51 2 40 013 51 2 50 013 51
5 2 Bolt, valve stop PE 2 15 014 51 2 25 014 51 2 40 014 51 2 50 014 51
6 2 Valve stop, discharge valve PE 2 15 015 51 2 25 015 51 2 40 015 51 2 50 015 51
7 2 Plug, side housing PE 2 15 017 51 2 25 017 51 2 40 017 51 2 50 017 51
8 1 Plug, center housing PE 2 15 019 51 2 25 019 51 2 40 019 51 2 50 019 51
9 4 Cylinder valve, code E.Y PE 2 15 016 51 2 25 016 51 2 40 016 51 2 50 016 51
Cylinder valve, code E.Z PTFE 2 15 016 60 2 25 016 60 2 40 016 60 2 50 016 60
Ball valve, code E.E EPDM 1 15 032 72 1 25 032 72 1 40 032 72 1 50 032 72
Ball valve, code E.S
Stainless
steel
1 15 032 22 - - -
Ball valve, code E.T PTFE 1 15 032 60 1 25 032 60 1 40 032 60 1 50 032 60
10 4 Valve seat PE 2 15 018 52 2 25 018 52 2 40 018 52 2 50 018 52
11 8 O-ring, sleeve, code EE. EPDM 9 20 631 72 9 33 632 72 9 50 633 72 9 62 634 72
O-ring. sleeve, code ET. FEP/FKM 9 20 631 59 9 33 632 59 9 50 633 59 9 62 634 59
12 2 O-ring, valve stop, discharge valve, code EE. EPDM 9 24 625 72 9 38 626 72 9 57 627 72 9 76 628 72
O-ring, valve stop, discharge valve, code ET. FEP/FKM 9 24 625 59 9 38 626 59 9 57 627 59 9 76 628 59
13 4 Shock absorbers NR 1 15 322 85 1 15 322 85 1 40 322 85 1 40 322 85
14 2 Diaphragm, code EE. EPDM 1 15 031 72 1 25 031 72 1 40 031 72 1 50 031 72
Diaphragm, code ET. PTFE 1 15 031 67 1 25 031 67 1 40 031 67 1 50 031 67
15 ** Housing bolt, cpl. 1.4301 2 15 020 22 2 25 020 22 2 40 020 22 2 50 020 22
16 1 Shaft 1.4301 2 15 030 22 2 25 030 22 2 40 030 22 2 50 030 22
17 2 Set screw, shaft 1.4305 9 10 220 22 9 12 221 22 9 16 222 22 9 20 223 22
18 2 Shaft piston ring, cpl. PTFE 1 15 041 64 1 25 041 64 1 40 041 64 1 50 041 64
19 1 Air inlet PETP 1 15 047 84 1 15 047 84 1 40 047 84 1 40 047 84
20 1 Air filter PE 1 15 043 51 1 15 043 51 1 40 043 51 1 40 043 51
21 1 Muffler, cpl. PE 1 15 244 51 1 15 244 51 1 40 244 51 1 50 244 51
22 1 PERSWING P® air control system, cpl. PETP 2 15 001 84 2 15 001 84 2 40 001 84 2 50 201 84***
24* 6 O-ring, air valve housing NBR 9 36 504 71 9 36 504 71 9 46 515 71 9 66 533 71
* included in Pos. 22 ** A 15 and A 25: 6 pieces; A 40 and A 50: 8 pieces
*** effective from serial number 550878, prior pumps equipped with 2 50 001 84
Please see page 2 for explanation of the pump code.
When ordering please state the serial number of the pump.
Spare part lists for possible options in separate manual.
