Almatec A 25 - Spare Part List (UEE - UTZ)

13
Spare part list ALMATEC A-Series, UEE – UTZ
Material housing parts: PTFE conductive
Pump size A 08 U.. A 10 U.. A 15 U.. A 25 U.. A 40 U.. A 50 U..
Item Pc. Description Material Part-No. Part-No. Part-No. Part-No. Part-No. Part-No.
1 2 Side housing
PTFE
conductive
2 08 010 65 2 10 010 65 2 15 010 65 2 25 010 65 2 40 010 65 2 50 010 65
2 1 Center housing
PTFE
conductive
2 08 011 65 2 10 011 65 2 15 011 65 2 25 011 65 2 40 011 65 2 50 011 65
3 4 Sleeve
PTFE
conductive
2 08 012 65 2 10 012 65 2 15 012 65 2 25 012 65 2 40 012 65 2 50 012 65
4 2 Valve stop, suction valve
PTFE
conductive
2 08 013 65 2 10 013 65 2 15 013 65 2 25 013 65 2 40 013 65 2 50 013 65
5 2 Bolt, valve stop
PTFE
conductive
2 08 014 65 2 10 014 65 2 15 014 65 2 25 014 65 2 40 014 65 2 50 014 65
6 2 Valve stop, discharge valve
PTFE
conductive
2 08 015 65 2 10 015 65 2 15 015 65 2 25 015 65 2 40 015 65 2 50 015 65
7 2 Plug, side housing
PTFE
conductive
2 08 017 65 2 10 017 65 2 15 017 65 2 25 017 65 2 40 017 65 2 50 017 65
8 1 Plug, center housing
PTFE
conductive
2 10 019 65 2 10 019 65 2 15 019 65 2 25 019 65 2 40 019 65 2 50 019 65
9 4 Cylinder valve, code U.Z PTFE 2 08 016 60 2 10 016 60 2 15 016 60 2 25 016 60 2 40 016 60 2 50 016 60
Ball valve, code U.E EPDM 1 10 032 72 4 15 032 72 1 15 032 72 1 25 032 72 1 40 032 72 1 50 032 72
Ball valve, code U.S
Stainless
steel
1 10 032 22 4 15 032 22 1 15 032 22 - - -
Ball valve, code U.T PTFE 1 10 032 60 4 15 032 60 1 15 032 60 1 25 032 60 1 40 032 60 1 50 032 60
10 4 Valve seat
PTFE
conductive
2 08 018 65 2 10 018 65 2 15 018 65 2 25 018 65 2 40 018 65 2 50 018 65
11 8 O-ring, sleeve, code UE. EPDM - 9 15 630 72 9 20 631 72 9 33 632 72 9 50 633 72 9 62 634 72
O-ring. sleeve, code UT. FEP/FKM 9 12 629 59 9 15 630 59 9 20 631 59 9 33 632 59 9 50 633 59 9 62 634 59
12 2
O-ring, valve stop, discharge
valve, code UE.
EPDM - 9 19 624 72 9 24 625 72 9 38 626 72 9 57 627 72 9 76 628 72
O-ring, valve stop, discharge
valve, code UT.
FEP/FKM 9 16 623 59 9 19 624 59 9 24 625 59 9 38 626 59 9 57 627 59 9 76 628 59
13 4 Shock absorbers NR 1 08 322 85 1 08 322 85 1 15 322 85 1 15 322 85 1 40 322 85 1 40 322 85
14 2 Diaphragm, code UE. EPDM - 1 10 031 72 1 15 031 72 1 25 031 72 1 40 031 72 1 50 031 72
Diaphragm, code UT. PTFE 1 08 031 67 1 10 031 67 1 15 031 67 1 25 031 67 1 40 031 67 1 50 031 67
15 ** Housing bolt, cpl. 1.4301 2 08 020 22 2 10 020 22 2 15 020 22 2 25 020 22 2 40 020 22 2 50 020 22
16 1 Shaft 1.4301 2 08 030 22* 2 08 030 22* 2 15 030 22 2 25 030 22 2 40 030 22 2 50 030 22
17 2 Set screw, shaft 1.4305 - - 9 10 220 22 9 12 221 22 9 16 222 22 9 20 223 22
18 2 Shaft piston ring, cpl. PTFE - - 1 15 041 64 1 25 041 64 1 40 041 64 1 50 041 64
19 1 Air inlet PETP 1 08 047 84 1 08 047 84 1 15 047 84 1 15 047 84 1 40 047 84 1 40 047 84
20 1 Air filter PE - - 1 15 043 51 1 15 043 51 1 40 043 51 1 40 043 51
21 1 Muffler PE/Bz 1 08 244 51 1 08 244 51 1 15 244 34 1 15 244 34 1 40 244 34 1 40 244 34
22 1
PERSWING P® air control
system, cpl.
PETP 2 08 001 84 2 08 001 84 2 15 001 84 2 15 001 84 2 40 001 84
2 50
201 84***
24* 6 O-ring, air valve housing NBR 9 26 519 71 9 26 519 71 9 36 504 71 9 36 504 71 9 46 515 71 9 66 533 71
* included in Pos. 22 ** A 08 and A 10: 4 pieces; A 15 and A 25: 6 pieces; A 40 and A 50: 8 pieces
*** effective from serial number 549677, prior pumps equipped with 2 50 001 84
Please see page 2 for explanation of the pump code.
When ordering please state the serial number of the pump.
Spare part lists for possible options in separate manual.
