Alpha-InnoTec LW - Condensate Discharge; Pressure Relief; Separating Buffer TANK; Circulating Pumps

15
We reserve the right to modify technical specifications without prior notice.
83051400aUK © Alpha-InnoTec GmbH
The ow direction of the hot water system must also be
rotated via the switching valve during cooling.
hydraulic diagram see page 31
V
separating buffer tank
=
minimum ow rate of heat circuit
volume ow / hour
10
For the minimum ow rate of the heat
circuit volume ow, see overview “Technical
data / Scope of delivery”, “Heating circuit”
section.
Circulating pumps
ATTENTION
Always note the model.
Do not use unregulated circulating pumps.
Circulating pumps and domestic hot water cir-
culation pumps must be multi-stage, regulated
pumps.
Water heating
Water heating with the heat pump requires an addition-
al hot water circuit, parallel to the heating circuit. Make
sure that the heating water charge is not channelled
through the buffer tank of the heating circuit.
“Hydraulic connection” instructions.
Hot-water tank
If the heat pump will be used for heating hot water, you
must integrate special hot-water tanks in the heat pump
system. The storage volume must be sufcient so that
the required hot water quantity is available even during
a power cut.
Install the condensate water hose in the unit so that
there is no contact with refrigerant pipes.
Make sure that frost-free condensate discharge is
ensured.
Installation plan for respective model.
Heat pump planning manual.
Seal empty pipes on unit side.
CondensatedisCharge
The condensate from the air must be discharged frost-
free via a condensate pipe with a minimum diameter of
50 mm. For underlying surfaces that are permeable to
water, it is sufcient to insert the condensate pipe ver-
tically at least 90 cm into the ground. If the condensate
is discharged into drainage or sewage systems, install
frost-free with gradient.
Discharge of the condensate into the sewage system
is permitted only via a funnel siphon, which must be
accessible at all times.
Pressure relief
Equip the heating circuit in accordance with local
standards and directives with a safety valve and an
expansion tank.
Also install lling and emptying devices, shut-off devices
and non-return valves in the heating circuit.
Separating buffer tank
The hydraulic integration of the heat pump is only
permissible with a separating buffer tank (Isolation
against vapour diffusion).
