1. Introduction
11
© 2002
TM
016-537-B0-002 Rev. B
Table 1-1; Specifications
* Figures shown reflect use with power cord supplied with unit.
For 22A @120V, use optional 30A 125V cord (27 A max).
† Output voltage w/ input frequency = 60Hz. Otherwise ±10%
MODEL APP 9015S APP 9022S
Input Voltage (VAC) 120/240 ± 15% 120/240 ± 15%
Input Frequency
(Hz)
60 ± 3% 60 ± 3%
Input Current
(A)
12 12.5 @ 240 VAC max*
22 @ 120 VAC max*
Output Voltage
(VAC)
60/75/90 ± 5%† 60/75/90 ± 5%†
Output Current (A) 15 Continuous
Output Power (VA)
(Continuous)
1350
Output Current Limit 150% of Output
Rating
150% of Output
Rating
Efficiency 90% typical
@rated load
90% typical
@rated load
Finish Flat Black Flat Black
Operating
Temperature Range
-40° F to +122° F
(-40° C to +50° C)
-40° F to +122° F
(-40° C to +50° C)
Dimensions (in/mm)
(H x W x D)
9" x 9.5" x 13.75"/
241 x 229 x 349
9" x 9.5" x 13.75"/
241 x 229 x 349
Weight (lbs/kg) 47/21 60/27
Enclosure Type NEMA 1 NEMA 2
1350/1650/1950
17 (120 VAC in*)
22 Continuous
(240 VAC in*)
The APP Service Power Supply (SPS) is a portable device used to provide temporary power while
the existing power supply is being serviced. The APP SPS can be used in either pole- or ground-
mount enclosures to provide signal processing equipment in Cable Television and Broadband LAN
distribution systems with current-limited, regulated AC power.
The APP SPS contains a front panel ammeter to measure the output current to the load; an output
breaker to protect against excessive short circuit currents; an "Output" indicator to verify AC output
power; an input breaker to provide additional voltage protection; and a 60/75/90 VAC switch for
output voltage selection.
1.1 The APP Service Power Supply
