1. Introduction
13
© 2002
TM
016-537-B0-002 Rev. B
1.3 APP Service Power Supply Features, continued
Output Voltage Selector
The VAC switch is used to select the desired output voltage. Output options are 60, 75 and
90 Volts.
NOTE: Verify that output voltage settings are correct before connecting load to
supply. Do not rotate switch when unit is in operation. Always remove
power from unit when selecting output settings.
60/ 75/ 90 VAC Output Connector
The 60/ 75/ 90 VAC output connector supplies up to 22 Amps of power to a Service Power
Inserter (SPI) through an output cable.
Output Cables
9015S:
Included with the APP 9015S is an output cable used to connect the Service Power Supply
to the SPI, via a four-pin Jones connector.
9022S:
Included with the APP 9022S are two 6-ft output "Y" cables. One cable terminates with two
Jones connectors, and provides service power to one or two separate 20A SPIs. The other
cable terminates with two 25A connectors, for 25A SPIs.
Input Connector
Input Connector is used to connect the APP SPS to line power through an AC line cord.
The cord plugs directly into enclosure convenience outlet.
9015S:
Includes two power cords for 120VAC or 240VAC operation.
NOTE: Before connecting power cord, Input voltage must first be selected via the
120/240 Input Voltage Selector switch.
9022S:
Includes two power cords. One with a 5-20P plug to set voltage to 120 VAC; and one with a
6-15P plug to set voltage to 240 VAC.
9022s Option: 30-Ft Output Cables
A 30-foot output kit is available. This kit provides "Y" cables for both 25A and Jones
connectors. Alpha part number: 745-094-20.
9022S Option: 10-Ft Cord w/30A Connector and Twist Lock Plug (125VAC)
For full current output with a 120 VAC input, use with a twist lock receptacle. This line cord
is equipped with a NEMA L5-30P plug. Alpha part number: 874-935-22.
