Alpha DCX Series - 5 Product Specifications

To Next Page

To Previous Page

C048-699-30 R03, Rev. B (01/2021)

5.0 5.0 Product SpecicationsProduct Specications

Table 7. Technical Specications

ELECTRICAL

Voltage ±48VDC, ±24VDC

Input Current 400A, 600A, 800A, 1000A, 1200A

Alarm Contacts Form-C, 60VDC @ 0.5A max.

Breaker AIC 50kA (800/1000A), 100kA (400/600/1200A)

Shunt Rating 50mV/1200A

CONNECTIONS

Communications Battery

Positive

Terminal block; #14-16 AWG

Output Termination 1/2 in. Threaded insert; 1.75 in. CTC (4 positions)

3/8 in. Threaded insert; 1 in. CTC (3 positions)

Chassis Ground 1/4 in. Threaded stud; 5/8 in. CTC (2 positions)

MECHANICAL

Dimensions (in.) L x H x D 13.5 x 15 x10

Weight 22 lbs.

ENVIRONMENTAL

Operating Temperature 50ºC Operating

Humidity 0 to 95% RH Non-Condensing

Elevation -500 to 2800m

Table 8. Agency Certications

UL File Number E473904

UL Standard ANSI/UL 60950-1
