Alpha DCX Series - 6 Models and Accessories

15
C048-699-30 R03, Rev. B (01/2021)
6.0 6.0 Models and AccessoriesModels and Accessories
NOTE: For latest part numbers and compatibility, please refer to DCX ordering guide (Doc. #C048-014-01).
Mounting kit designs are based on the latest available battery stack information provided by the battery manufacturers.
Table 9. DCX Model Congurations - Switch Only Versions (No Current Limiting)
DESCRIPTION PART NUMBER
400A DCX Battery Disconnect, -48VDC, w/shunt C016-1001-10
600A DCX Battery Disconnect, -48VDC, w/shunt C016-1003-10
800A DCX Battery Disconnect, -48VDC, w/shunt C016-1005-10
1000A DCX Battery Disconnect, -48VDC, w/shunt C016-1007-10
1200A DCX Battery Disconnect, -48VDC, w/shunt C016-1009-10
Table 10. DCX Model Congurations - Magnetic Trip Versions
DESCRIPTION PART NUMBER
400A DCX Battery Disconnect, -48VDC, w/shunt C016-198-10
600A DCX Battery Disconnect, -48VDC, w/shunt C016-195-10
800A DCX Battery Disconnect, -48VDC, w/shunt C016-199-10
1000A DCX Battery Disconnect, -48VDC, w/shunt C016-196-10
1200A DCX Battery Disconnect, -48VDC, w/shunt C016 -207-10
Table 11. Battery Mounting Bracket Kits - For EnerSys
®
Batteries
DESCRIPTION APPLICABLE
BATTERY
SYSTEM
3X8 CONFIG. 4X6 CONFIG. PART NUMBER
DCX Mount Kit, EnerSys DDmP50-17, 3X8 DDmP50-17 • C016-2314-10
DCX Mount Kit, EnerSys DDmP50-17, 4X6 DDmP50-17 • C016-2300-10
DCX Mount Kit, EnerSysDDmP85-15, 4x6 DDmP85-15 • C016-2320-10
DCX Mount Kit, EnerSys DDmP85-21, 3X8 DDmP85-21 • C016-2315-10
DCX Mount Kit, EnerSys DDmP85-21, 4X6 DDmP85-21 • C016-2301-10
DCX Mount Kit, EnerSys DDmP100-21, 3X8 DDmP100-21 • C016 -2311-10
DCX Mount Kit, EnerSys DDmP100-21, 4X6 DDmP100-21 • C016-2312-10
DCX Mount Kit, EnerSys DDmP100-25, 3X8 DDmP100-25 • C016-2316-10
DCX Mount Kit, EnerSys DDmP100-25, 4X6 DDmP100-25 • C016-2302-10
DCX Mount Kit, EnerSys DDmP100-33, 3X8,
4X6
DDmP100-33 • • C016-2317-10
DCX Mount Kit, EnerSys DDmP125-25, 3X8 DDmP125-25 • C016-2322-10
DCX Mount Kit, EnerSys DDmP125-25, 4X8 DDmP125-25 • C016-2323-10
DCX Mount Kit, EnerSys DDmP125-33, 3X8,
4X6
DDmP125-33 • • C016-2318-10
DCX Mount Kit, EnerSys mP50-17, 3X8 mP50-17 • C016-2303-10
DCX Mount Kit, EnerSys mP50-17, 4X6 mP50-17 • C016-2304-10
DCX Mount Kit, EnerSys mP85-15, 4X6 mP85-15 • C016-2321-10
DCX Mount Kit, EnerSys mP85-21, 3X8 mP85-21 • C016-2305-10
DCX Mount Kit, EnerSys mP85-21, 4X6 mP85-21 • C016-2306-10
DCX Mount Kit, EnerSys mP100-25, 3X8 mP100-25 • C016 -2307-10
DCX Mount Kit, EnerSys mP100-25, 4X6 mP100-25 • C016-2308-10
DCX Mount Kit, EnerSys mP100-33, 3X8, 4X6 mP100-33 • • C016-2309-10
DCX Mount Kit, EnerSys mP125-25, 3X8 mP125-25 • C016-2310-10
DCX Mount Kit, EnerSys mP125-25, 4X6 mP125-25 • C016-2313-10
DCX Mount Kit, EnerSys mP125-33, 3X8, 4X6 mP125-33 • • C016-2319-10
