Alpha InTec² 25XE and 28XE - Commissioning
Fan Speed set values according to boiler model and 'F' parameter (flue setting)Parameter G
Sub-menu s
InTec
2
25X
F parameter setting
InTec
2
28X
F parameter setting
F = 0
13
(1300 rpm)
56
(5650 rpm)
39
(3950 rpm)
F = 1
13
(1350 rpm)
58
(5800 rpm)
39
(3950 rpm)
F = 2
13
(1375 rpm)
59
(5900 rpm)
39
(3950 rpm)
F = 0
14
(1400 rpm)
61
(6100 rpm)
37
(3700 rpm)
F = 1
14
(1425 rpm)
63
(6350 rpm)
37
(3700 rpm)
F = 2
14
(1450 rpm)
64
(6400 rpm)
37
(3700 rpm)
S2 (ignition fan speed)
S1 (max. fan speed)
S0 (min. fan speed)
Note: These must be set to the correct values relating to the boiler installed. When changed 'E62' will be displayed and full
calibration is required. See Section 5.13.
Parameter Feature Description Range
0 - 99 %
0 - P2
0 - 99 %
0 - 7
0 - 7
0 - 9
0 - 1
-9 +9 °C
-
The maximum output of the boiler during DHW production as a
percentage of the maximum available output
The minimum heat output of the boiler during DHW and CH
production as a percentage of the available heat output
The maximum output of the boiler during CH production as a
percentage of the naximum available output
Boiler functions/configurations when optional relay PCB is fitted
0 = Off
1 = Main zone control (with Climatic controller)
2 = General alarm
3 = CH phase active (external pump)
4 = External gas valve power supply
5 = Flow Smart enabled
6 = Diverter valve enabled
7 = When boiler pump active
Boiler functions/configurations when optional relay PCB is fitted
0 = Off
1 = General alarm
2 = CH phase active (external pump)
3 = External gas valve power supply
4 = Secondary zone control (volt free switching across
57 & 58 on relay PCB contacts)
5 = Heat pump function with dedicated controls
6 = Alpha Trace heating cable enabled
7 = When boiler pump active
Boiler functions/configurations when optional relay PCB is fitted
0 = Off
1 = Chiller remote activation (with Climatic controller)
2 = General alarm
3 = CH phase active (external pump)
4 = External gas valve power supply
5 = Heat pump function with dedicated controls
6 = Activation of storage tank pump
7 = Main zone control (with Climatic controller)
8 = Alpha Trace heating cable enabled
9 = When boiler pump active
The pump can function in two ways.
0 Intermittent - In Winter mode the pump is managed by the
room thermostat or by the remote control
1 Continuous - In Winter mode the pump is always on
If the reading of the external sensor is incorrect it is possible to
offset the reading.
(Over the value of +9 the display shows 'CE', for external control
connection only used with system supervisor connection)
Not used on this boiler model
DHW max.
Min. output
DHW and CH
Heating max.
Relay 1
(optional)
Relay 2
(optional)
Relay 3
(optional)
Pump functioning
External sensor
correction
-
P0
P1
P2
P3
P4
P5
P6
P7
P8
Default
99 %
0 %
1
6
0
0
0
-
25XE - 85 %
25XE (LPG) - 77 %
28XE - 85 %
28XE (LPG) - 81 %
