Alpine CDA-9855R User Manual

CDA-9855R
No. Voltage Note No. Voltage Note No. Voltage Note
1 NC 16 4.6 31 4.24
2 NC 17 NC 32 4.24
3 4.24 18 3.55 33 4.24
4 4.24 19 0 34 4.24
5 4.24 20 PS 35 4.24
6 4.24 21 PS 36 4.24
7 4.24 22 8.5 37 4.24
8 4.24 23 NC 38 4.24
9 4.24 24 NC 39 4.24
10 4.24 25 4.24 40 4.24
11 4.24 26 4.24 41 NC
12 4.24 27 4.24 42 NC
13 4.24 28 4.24 43 NC
14 3.7 29 4.24 44 NC
15 PS 30 4.24
No. Voltage Note No. Voltage Note No. Voltage Note
1 4.26 6 4.26 11 0
2 4.26 7 4.26 12 4.26
3 4.26 8 4.26 13 4.26
4 8.55 9 4.26 14 4.26
5 4.26 10 4.26
No. Voltage Note No. Voltage Note
1 4.26 1 0
2 4.26 2 0
3 4.26 3 0
4 0 4 -8.1
5 PS 5 0
6 PS 6 0
7 PS 7 0
8 8.56 8 8.55
No. Voltage Note No. Voltage Note No. Voltage Note
1 0 6 0 11 -8.1
2 0 7 0 12 0
3 0 8 0 13 0
4 8.55 9 0 14 0
5 0 10 0
IC306
IC204
IC301
IC302 IC305
