CDA-9855R
No. Voltage Note No. Voltage Note No. Voltage Note
1 0 10 7.9 19 7.62
2 0 11 1.72 20 14.3
3 7.62 12 1.6 21 7.62
4 4.85 13 0 22 0
5 7.62 14 1.63 23 7.62
6 14.3 15 1.47 24 0
7 7.62 16 1.33 25 3.59
8 0 17 7.62
9 7.62 18 0
No. Voltage Note No. Voltage Note No. Voltage Note
1 3.33 35 3.33 69 0
2 0 36 4.95 70 3.33
3 PS 37 3.33 CD 71 NC
4 PS 38 0/3.33 TUNER/CD 72 3.33/0 NOSE CLOSE/OPEN
5 3.33 39 PS 73 3.33
6 3.33 40 PS 74 0/3.27 CD
7 3.33 41 PS 75 0/3.33 2WAY/3WAY
8 0 42 PS 76 0
9 3.33 43 PS 77 0/3.33 NOSE CLOSE/OPEN
10 2.55 44 PS 78 3.33
11 0 45 0/3.33 BUZZER OFF/ON 79 3.33
12 1.17 46 PS 80 0/3.33 FAN OFF/ON
13 1.21 47 PS 81 0/3.33 CD/TUNER
14 3.33/0 RESET OFF/ON 48 PS 82 3.33
15 NC 49 3.33 83 3.33
16 NC 50 PS 84 0/3.33 IF MUTE OFF/ON
17 3.33 51 PS 85 0/3.33 RDS CONT OFF/ON
18 4.94 52 PS 86 0/3.33 BW CONT OFF/ON
19 4.91 53 PS 87 0/3.33 DOOR LED OFF/ON
20 0/3.27 TUNER/CD 54 PS 88 0/3.33 MOTOR OFF/ON
21 PS 55 PS 89 0/3.33 BL-LED OFF/ON
22 PS 56 PS 90 2.9
23 PS 57 PS 91 0/3.33 ADJCH OFF/ON
24 PS 58 PS 92 0/3.00 FM/AM
25 PS 59 3.33 93 2.88 HI-TEMP
26 PS 60 3.33 94 0/3.33 DISC IN
27 3.33/PS 61 0/3.17 DIMMER ON/OFF 95 0/3.33 POWER ON/OFF
28 3.33 62 3.33/0 POW IC ON/OFF 96 PS
29 4.94/0 REMOCON OFF/ON 63 3.33 97 1.76
30 3.33 64 3.33/0 FM/AM 98 2.5
31 4.9 65 0/3.33 A MUTE ON/OFF 99 3.13
32 3.33 66 3.33/0 INT ON/OFF 100 1.64
33 0 67 3.33
34 3.33 68 NC
IC501
IC307
