Alpine CDA-9855R User Manual

CDA-9855R
No. Symbol I/O Terminal Description
48 F-START O Front u-COM communication start output terminal.
49 F-RESET O Front u-COM RESET signal output terminal.
50 AMP DATA IN I AMP LINK DATA input terminal.
51 AMP DATA OUT O AMP LINK DATA output terminal.
52 AMP CLK O AMP LINK CLOCK output terminal.
53 F-IN I Data signal input terminal from Front u-COM.
54 F-OUT O Data signal output terminal to Front u-COM.
55 F-CLK I Clock signal input terminal from Front u-COM.
56 CD QDATAF I CD QDATA input terminal.
57 OEM SUB DATA O OEM SUB DISPLAY DATA output terminal.
58 OEM SUB CLK O OEM SUB DISPLAY CLK output terminal.
59 NOSE POWER O NOSE POWER control output terminal.
60 AUTO ADJ I TUNER auto adjustment input terminal.
61 IN DIMMER I DIMMER signal input terminal.
62 PWR IC ON O POWER IC control output terminal.
63 O-REM O OUT-REM signal output terminal.
64 FM/AM O TUNER power supply control signal output terminal. (Hi : FM, Lo : AM)
65 A.MUTE O A-MUTE output terminal.
66 ININT I IN INT input terminal.
67 DSP RESET O DSP RESET output terminal.
68 ARIA1(NC) - No connect terminal.
69 BVSS - GND connect terminal.
70 BVDD - VDD connect terminal.
71 NC - No connect terminal.
72 LIMIT SW1 I Swing Mech SW1 input terminal.
73 VDD PULLUP O Pull-up resistor power supply control output terminal.
74 ZERO-DET I ZERO DET signal input terminal.
75 2WAY/3WAY I 2WAY / 3WAY switching input terminal.
76 FLMD1(NC) - No connect terminal.
77 LIMIT SW2 I Swing Mech SW2 input terminal.
78 V-CONT(NC)
79 P-ANT(NC)
80 FAN CONT O FAN CONT output terminal.
81 CONT2
82 CONT1
83 P-CONT O POWER CONTROL output terminal.
84 IF MUTE O IF MUTE output terminal.
85 RDS CONT O RDS control output terminal.
86 BW CONT(NC) - No connect terminal.
87 DOOR LED O DOOR LED control terminal.
88 MOTOR ON O MOTOR power supply control terminal.
89 BL-LED O Backlight LED power supply control terminal.
90 DAVN I DAVN input terminal.
91 ADJCH DET I ADJCH detection input terminal.
92 AM SD I TUNER Seek Stop signal input terminal.
93 HI-TEMP I CD HI-TEMP signal input terminal.
94 DISC IN I CD DISC-IN detection signal input terminal.
95 VHH CONT O VHH CONT output terminal.
- No connect terminal.
O Power supply IC control terminal.
