10-EN
3
Press RESET with a ballpoint pen or similar pointed object.
Adjusting Volume
Turn the Rotary encoder until the desired sound is
obtained.
Setting Time
1
Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP selection mode.
2
Turn the Rotary encoder to select GENERAL, and then
press ENTER.
AUDIO GENERAL DISPLAY TUNER iPod
BLUETOOTH
*
* CDE-133BT only.
3
Turn the Rotary encoder to select the CLOCK ADJ mode,
and then press ENTER.
The time indication will blink.
4
Turn the Rotary encoder to adjust the hours while the
time indication is blinking.
5
When the hour has been adjusted, press ENTER.
6
Turn the Rotary encoder to adjust the minutes while the
time indication is blinking.
7
Press and hold AUDIOSETUP for at least 2 seconds to
return to normal mode.
Notes
To synchronize the clock to another clock/watch or radio time
announcement, press and hold ENTER for at least 2 seconds after
setting the “hour”. Minutes will reset to “00”. If the display shows over
“30” minutes when you do this, the time will advance one hour.
Pressing will return to the previous mode.
Pressing and holding for at least 2 seconds will return to normal
mode.
If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
Even when AUTO CLOCK is set to ON (refer to “Setting the Time to
automatically Adjust” on page 12), the time can be adjusted manually.
At the same time, if there is an adjustment request from RDS, the time
will be adjusted automatically by RDS data.
RESET button
Controllable with Remote Control
This unit can be controlled with an optional Alpine remote control.
For details, consult your Alpine dealer. Point the optional remote
control transmitter at the remote-control sensor.
Remote control sensor

Table of Contents

Other manuals for Alpine CDE-133BT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Alpine CDE-133BT and is the answer not in the manual?

Alpine CDE-133BT Specifications

General IconGeneral
MP3 playbackNo
CD-R playbackYes
Playback disc formatsCD audio
Audio formats supportedMP3
FM band range87.5 - 108 MHz
LW band range153 - 281 kHz
Supported radio bandsFM, LW, MW
Preset stations quantity18
RDS featuresTA, TP
Product colorBlack
CD changer capacity1 discs
Disc types supportedCD, CD-R, CD-RW
Audio output channels4.0 channels
Equalizer bands quantity7
Signal-to-Noise Ratio (SNR)105 dB
Display typeLCD
Bluetooth version3.0+HS
Bluetooth profilesA2DP, AVRCP, HFP, HSP
Headphone connectivity3.5mm
Apple docking compatibilityiPhone, iPod
RMS rated power200 W
File format systemFAT32
Power requirements14.4V DC, 11-16V
Operating temperature (T-T)-10 - 60 °C
Weight and Dimensions IconWeight and Dimensions
Weight1500 g
Dimensions (WxDxH)178 x 161 x 50 mm
