26-EN
+
,
-
.
~
)
(
/
:
$
&
6
8
Rch
Sig Gnd
Lch
Data Ground
Data Bus
Battery
Shield Ground
lgnition
Power Supply Ground
%
!
#
"
A
3
5
9
7
4
2
;
1
Installation and Connections
Ignition Key
Battery
CD changer
(Sold separately)
Rear Left
Front Left
Front Right
Rear Right
Speakers
A
DIN Connector PIN Configuration
Antenna
To power antenna
To vehicle phone
To amplifier or equalizer
Connections
∗ When Subwoofer is set to OFF: Output is from Rear speakers.
When Subwoofer is set to ON: Output is from Subwoofer.
For details on how to set the Subwoofer to ON/OFF, see "Subwoofer On and Off" on page 6.
ISO Antenna Plug
Amplifier
Speakers
Rear or
Subwoofers∗
(Pink/Black) AUDIO INTERRUPT IN
(Blue/White) REMOTE TURN-ON
(Red) IGNITION
(Black) GND
(Blue) POWER ANT
(Yellow) BATTERY
Green/Black
Green
White/Black
White
Grey
Grey/Black
Violet
Violet/Black
To Next Page
