Basic
Adjusting Volume/Balance
(Between Left and Right)/Fader
(Between Front and Rear)
1 Press the MODE button repeatedly to choose
the desired mode.
Each press changes the modes as follows:
NOTES
• If the 5 or 6 button is not pressed in 5 seconds after
selecting the BAL, or FAD mode, the unit
automatically sets in the VOL mode.
• When the subwoofer, BBE mode is set to ON, the
level of the subwoofer, BBE can be adjusted.
2 Press the
55
55
5 or
66
66
6 button until the desired sound is
obtained in each mode.
→ VOL → BAL → FAD
Selecting BBE Mode
(TDM-7585R only)
The BBE (Barcus Berry Electronics) processor
installed in this unit is designed to correct the
phase distortion inherent in most loudspeaker
designs. Ensuring the phase integrity of the
signal driving the speakers improves the
accurate reproduction of the sound.
1 Press and hold the BBE button for at least 2
seconds to turn BBE on.
Each press toggles between the BBE on and off
modes.
2 In BBE mode, press the BBE button to switch to
the BBE adjusting mode.
NOTE
In BBE adjusting mode, wait 5 seconds without
pressing any button. The BBE adjusting mode is turned
OFF.
3 To change to a desired BBE level, press the
55
55
5 or
66
66
6 buttons.
The BBE level can be changed from +1 to +3.
BBE Mode On/Off
(CDM-7870R only)
The BBE (Barcus Berry Electronics) processor
installed in this unit is designed to correct the
phase distortion inherent in most loudspeaker
designs. Ensuring the phase integrity of the
signal driving the speakers improves the
accurate reproduction of the sound.
1 Press and hold the BBE button for at least 2
seconds to turn on the BBE mode.
Each press toggles between the BBE on and off
modes.
→ FM LV ←→ REG ←→ SUB ←
→ AUX ←→ 100kHz/50kHz ←
Adjusting Source Signal Levels
If the difference in volume level between the CD
player and FM radio is too great, adjust the FM
signal level as follows.
1 Press and hold the SETUP button for at least 3
seconds.
2 Press the g DN or f UP button to select
the FM signal level mode.
3 Press the BAND button to select the FM signal
level HI (High) or LO (Low) to make the signal
levels between the FM band and CD player and
cassette player closer.
4 After setting is completed, press the SETUP
button to return to normal mode.
