Chevrolet/GMC
FULL SIZE TRUCK z 13/17
X110-G Restyle Bezel Assembly
1 Attach the factory HVAC controller by clipping it to
the X110-G Restyle bezel.
2 Attached the top and bottom brackets to the
X110-G display using the provide 8mm screws.
3 Mount the display monitor to the restyle panel using
(4) 8mm screws.
Exploded-View Diagram
OEM Climate Controller
TEMP
A/
C
To Next Page
