Chevrolet/GMC
FULL SIZE TRUCK z 14/17
Installation Instructions
1 Connect the steering wheel T-harness/OBDII
connector extension and route the cable to the
radio location.
OBDII Connector
SW T-Harness
2 Slide the X110-G radio tuner into the factory tuner
location and connect it to the main harness.
3 Attached the updated Maestro module to the main
harness and plug the main harness to the vehicle.
4 Connect the DVD player power harness and HDMI
cable from the DVD player to the X110-G.
5 Mount the DVD player it using (2) 7mm factory
screws.
6 Connect the HVAC controller T-harness.
To Next Page
