Chevrolet/GMC
FULL SIZE TRUCK z 15/17
Installation Instructions
7 Connect the X110-G to the main harness and
antenna connections.
8 Connect the X110-G display and snap into place.
Display Cable
Power
Key Harness
Climate Control
9 Secure the X110-G restyle bezel using (4) 7mm
factory screws.
10 Attach the side vent covers.
A/C
MENU
CAM
WAV
11 Connect the battery terminal and begin the X110-G
setup.
To Next Page
