ALSA ALSATOM SU 100 MPC - Setting of Minimum and Maximum HF Output Power Levels; Setting of Current Limit

ALSATOM SU MPC series – SERVICE MANUAL
- alsa apparecchi medicali s.r.l. -
6
HF MAXIMUM OUTPUT POWER LEVELS AND WAVEFORMS CHECK IN ALL MODES
Switch ON the unit in normal mode (J11 opened); check if at the end of selftest, no error occurs.
Start the unit in all modes setting maximum levels. Compare HF output power to diagrams included in
instructions manual (tolerance ±20% according to CEI EN 60601-2-2).
Maximum setting, nominal load for all modes reported in the following table:
MODE
NOMINAL
LOAD
(ohms)
SU140/D SU 140
SU 100
HF OUTPUT
POWER (W)
SU 50
HF
OUTPUT
POWER
(W)
SU 140/BD
HF OUTPUT
POWER (W)
CUT 500 140 80 100
BLEND 500 120 80 100
COAG 500 120 80
MICRO COAG 200 60 60
BIP 100 100 60 100
NOTE: in SU 140/BD MPC all bipolar modes only
Moreover, check HF output waveforms of every mode fit with the following pictures.
