Altai A8n (ac) Series Super WiFi Base Station
Installation Guide
Altai Technologies Ltd. All rights reserved
Cat 5e or cat 6 Ethernet cable are recommended. Maximum cable
length between PoE adapter and A8n (ac) is 100m.
The end of cable, RJ-45 modular jack pins are numbered 1 through 8 as
shown:
_______________________________
| | | | | | | | | |
| 8 7 6 5 4 3 2 1 |
|_____ Face of Plug ______|
|____ ____|
|________|
Tight up the screw nut into the Ethernet
connector of AP
