030519 A7 Owner's Manual 8
SPECIFICATIONS
Frequency response
±10 dB
35 Hz to 22 kHz
Low frequency roll-off
-3 dB
54 Hz
System power capacity
Rating based on test signal of
continuous pink noise, per IEC
spectrum for two hours duration.
200 W
Sensitivity
1 watt at 1 meter
97 dB
Nominal impedance 8 ohms
Crossover frequency 900 Hz
Nominal coverage 90° horizontal, 40° vertical
System polarity Positive voltage to RED produces
forward cone motion
Binding Posts Two pair. Jumpered for mono wiring.
Bi-amp capable. Accepts either spades
or bananas.
Finish Black, abrasion resistant splatter
Dimensions (W x D x H) 30 x 24 x 54 inches
Net system weight 170 lbs
