030519 A7 Owner's Manual 5
Step 9
Reattach the rear panel by using a 5/32” hex key to replace the bolts around the
perimeter of the rear panel.
Step 10
Reconnect the horn assembly wires as before, ensuring that the dark (blue) wire
is connected to the negative terminal and that the light (yellow) wire is connected
to the positive (+) terminal. The positive (+) terminal is marked and is on the right
side of the terminal block. Improper wiring of the horn assembly may result in the
speakers being out of phase.
Step 11
Insert grill over the bass reflex port.
