About This Development Kit
1
2017.08.08
UG-20005
Subscribe
Send Feedback
e Altera
®
Intel
®
Arria
®
10 GX Transceiver Signal Integrity Development Kit is a complete design
environment that includes both the hardware and soware you need to develop Arria 10 GX FPGA
designs. e one year license for the Intel Quartus Prime Design Suite
®
soware provides everything you
need to begin developing custom Arria 10 GX FPGA designs.
e following list describes what you can accomplish with the kit:
• Evaluate transceiver performance from 611 Mbps up to 17.4 Gbps.
• Generate and check pseudo-random binary sequence (PRBS) patterns.
• Dynamically change dierential output voltage (VOD) pre-emphasis, and equalization settings to
optimize transceiver performance for your channel.
• Perform jitter analysis.
• Verify physical medium attachment (PMA) compliance to PCI Express
*
(PCIe
*
), Gbps Ethernet (GbE),
XAUI, CEI-6G, Serial RapidIO
®
, high-denition serial digital interface (HD-SDI) and other major
standards.
Development Kit Features
is section lists and describes the contents of the Intel Arria 10 GX Transceiver Signal Integrity Develop‐
ment Kit.
Hardware
e Intel Arria 10 GX Transceiver Signal Integrity Development Kit includes the following hardware:
• Intel Arria 10 GX transceiver signal integrity development board—A development platform that allows
you to develop and prototype hardware designs running on the Intel Arria 10 GX FPGA device.
• Power supply and cables—e kit includes the following items:
• Power supply and AC adapters for North America, Japan, Europe and the United Kingdom
• USB type A to B cable
• Ethernet cable
Software
e new Intel Quartus
®
Prime design soware includes everything needed to design for Altera FPGAs,
SoCs and CPLDs from design entry and synthesis to optimization, verication and simulation. e Intel
Quartus Prime soware includes an additional Spectra-Q
®
engine that is optimized for future devices. e
Spectra-Q engine enables new levels of design productivity for next generation programmable devices
