#6001 COMBITHERM ELECTRIC INSTALLATION AND MAINTENANCE MANUAL
PG. 41
ELECTRICAL AND ELECTRONIC PARTS:
BOARD, DISPLAY CONTROL BA-33732 BA-33732 BA-33732 BA-33732 BA-33732 BA-33732
— ADJUSTING ROCKER (
COMPLETE) KN-33734 KN-33734 KN-33734 KN-33734 KN-33734 KN-33734
— ADJUSTING ROCKER KNOB KN-33735 KN-33735 KN-33735 KN-33735 KN-33735 KN-33735
— BUSHING, DISTANCE BU-25094 BU-25094 BU-25094 BU-25094 BU-25094 BU-25094
— NUT, KNURLED M3 NU-25095 NU-25095 NU-25095 NU-25095 NU-25095 NU-25095
BOARD, RELAY CONTROL BA-33736 BA-33736 BA-33736 BA-33736 BA-33736 BA-33736
BOARD, POWER SUPPLY BA-33554 BA-33554 BA-33554 BA-33554 BA-33554 BA-33554
BOARD, LED CLOSED SYSTEM BA-33733 BA-33733 BA-33733 BA-33733 BA-33733 BA-33733
BOARD, PROGRAM MODULE (
DELUXE MODELS) BA-33742 BA-33742 BA-33742 BA-33742 BA-33742 BA-33742
— CONNECTOR, X11/X12 (DELUXE MODELS ONLY) CR-33743 CR-33743 CR-33743 CR-33743 CR-33743 CR-33743
BOARD, COMMUNICATION 5000KM (OPTION) BA-33738 BA-33738 BA-33738 BA-33738 BA-33738 BA-33738
CONTACTORS, 20A, TYPE # DL4K-01 CN-3652 CN-3652 CN-3652 CN-3652 CN-3652 CN-3652
CONTACTORS, 25A, TYPE # DL7K-4H CN-3654 CN-3654 CN-3654 CN-3654 CN-3654 CN-3654
CONTACTORS, 50A, TYPE # DL15K-00 CN-3731 CN-3731 CN-3731 CN-3731 CN-3731 CN-3731
ELEMENT, HEATING, FLANGED IMMERSION 6 kW — EL-33412 EL-33412 EL-33412 EL-33412 EL-33412
ELEMENT, HEATING, FLANGED IMMERSION 9 kW EL-33411 EL-33411 EL-33411 EL-33411 EL-33411 EL-33411
ELEMENT, HEATING, CONVECTION (208-240
V, 1PH) EL-3854 EL-3761 EL-3761 ———
(208-240
V, 3PH) EL-3854 EL-3761 — EL-3979 EL-3853 EL-3853
(440-480V, 3PH) — EL-3761 EL-3761 EL-3853 EL-3853 EL-3853
ELEMENT, HEATING, CONVECTION MNTG HARDWARE
— WASHERS, FLAT WS-22294 WS-22294 WS-22294 WS-22294 WS-22294 WS-22294
— WASHERS, SPLIT LOCK WS-22300 WS-22300 WS-22300 WS-22300 WS-22300 WS-22300
— HEX NUTS NU-22286 NU-22286 NU-22286 NU-22286 NU-22286 NU-22286
— O-RING SA-23932 SA-23932 SA-23932 SA-23932 SA-23932 SA-23932
— WASHER, CONICAL 13607 13607 13607 13607 13607 13607
FAN, INTAKE, AUXILIARY DC4112NX FA-3568 FA-3568 FA-3568 FA-3568 FA-3568 FA-3568
FUSE, SLOW-BLO 2AMP, 250V FU-33184 FU-33184 FU-33184 FU-33184 FU-33184 FU-33184
FUSE, SC-5 (440-480V, 3PH ONLY) — FU-33581 FU-33581 FU-33581 FU-33581 FU-33581
FUSE, NEOZED 6.3AMP FU-33452 FU-33452 FU-33452 FU-33452 FU-33452 FU-33452
FUSE HOLDER, 6.3AMP (380-415V, 3PH ONLY) — FU-33451 ————
FUSE, 15AMP CLASS G (208-240
V, 1PH ONLY) FU-3775 FU-3775 FU-3775 FU-3775 FU-3775 FU-3775
FUSE HOLDER, 15
AMP CLASS G (208-240V, 3PH) FU-3772 FU-3772 FU-3772 FU-3772 FU-3775 FU-3772
FUSE HOLDER, 15AMP, 3POL, CLASS G (208-240V, 3PH) FU-3842 FU-3842 FU-3842 FU-3842 FU-3842 FU-3842
FUSE, 45AMP, MP, CLASS G ——FU-33040 FU-33040 FU-33040 FU-33040
FUSE HOLDER, DIN RAIL MOUNT WITH DISCONNECT FU-33756 FU-33756 FU-33756 FU-33756 FU-33756 FU-33756
FUSE HOLDER, 60AMP, 3POL, CLASS G — FU-33039 FU-33039 FU-33039 FU-33039 FU-33039
PART DESCRIPTION 6•10 7•14 10•10 10•18 12•20 20•20
Parts List • Combitherm ML Electric
