TROUBLESHOOTING
Vector™ H Seri es ▪ Serv ic e M anua l ▪ MN- 4654 4 ▪ Re v 01 ▪ 1 1/19
72
Continued from previous page
Calibrate the offset 10. Calibrate the offset number. Subtract the smaller value from the larger
value. This is the offset. If the value measured by the multimeter was the
larger value, the offset will positive “+”. If the value measured by the
multimeter was the smaller value, the offset will be negative “–”.
11. Enter the offset. To do so:
Touch the “>” icon j for the chamber offset temperature that needs to be
calibrated. The Enter offset screen displays.
Enter the value calibrated in step 10 and press the check mark. The
multimeter temperature and the temperature sensor should show the same
reading.
12. Repeat the procedure for the remaining chambers.
13. Cool the oven.
Result The chamber thermocouples have now been calibrated.
VMC-TS-008196
j
VMC-TS-008193
j
To Next Page
