INSTALLATION
Vecto r H® S eries ▪ Opera tor’s Manual ▪ M N-462 9 5 ▪ Rev 6 ▪ 1/22
46
Continued from previous page
2. While the oven is still on the lifting device, measure the distance between the
mounting holes of the legs/casters (X and Y).
3. Place the oven on the stand. Use the hole pattern d on the stand that
corresponds to the hole pattern of the oven measured in step 2. Connect the
oven to the stand using the hardware
e removed in step 1.
Result The oven is now installed to the stand.
