COMPONENTS
Vector™ H Seri es ▪ Serv ic e M anua l ▪ MN- 4654 4 ▪ Re v 01 ▪ 1 1/19
28
Terminal Blocks (VFDs and Cooling Fans)
Ref. Description
1 TB 4 - L2
2 TB 5 - L1
3 TB 6 - L2
(switched)
4 Ground
VMC-PHD-001939
1
2
3
4
