3
1.2 Technical data
Model 30CA
COMPACT
Type P478
Pump pressure bar 160
Water volume, min/max pressure l/min. 11.5 /10.3
Pre-priming, max. suction height m 1
Dosing of detergent % 0-5
Spray lance:
Spray angle h.p. / l.p. degrees 15 / 65
Nozzle type 035
Thrust, max. N/kp 26 / 2.65
1)
1 x 110V, 50 Hz (UK)
2)
1 x 100V, 50/60 Hz (J)
Data at 3 bar inlet pressure and 10°C inlet water.
Sound pressure level L
pA
measured in accordance with ISO 11202 [DISTANCE 1m] [FULL LOAD]: 83
dB(A).
We reserve the right to make alterations.
1.1 Model tag
This ALTO high pressure washer has the model
designation »30CA COMPACT /
30C/CA COMPACT I« and the type designation
»P478/P452«.
The model designation appears from the text on the
cabinet.
The model tag (pos. 15) provides the following details:
1. Model
2. Type
3. Serial no
4. Production year
5. Capacity
6. Max. pressure, opening pressure for by-pass valve
7. Working pressure
8. Max. inlet pressure
9. Max. temperature of inlet water
1.0 Survey of models GB
10. Rated output of motor
11. Mains frequency
12. Mains voltage
13. Number of phases
14. Power consumption of motor
15. Number of revolutions
16. COS
j
17. Classification of insulation
18. Classification of tightness
1
3
5
7
9
2
4
6
8
10
12
14
16
18
11
13
15
17
DK-9560 HADSUND
TLF . (+45) 7218 2100
MODEL
TYPE
SERIAL NO
PROD
U
CTION YEAR
CAPACITY
MAX. PRESSURE
WORKING PRESSURE
INLET PRESSURE
INLET TEMP ERATURE
MADE IN DENMARK
POWER
FREQUENCY
VOLTAGE
PHASE
POWER CUNSUMPTION
RPM
COS
ϕ
INSULATION CL.
MOISTURE RES. CL.
30CA 30CA 30CA 30C
COMPACT I COMPACT I
1)
COMPACT I
2)
COMPACT I
P452 P452 P452 P452
150 80 80 150
10 / 9 8.6 / 8.1 7.3 / 6.8 10 / 9
11 1 1
0-5 0-5 0-5 0-5
15 / 65 15 / 65 15 / 65 15 / 65
03 04 03 03
20 / 2.01 23 / 2.35 20 /2.01 20 / 2.01
