Alto AMX-100 Service Manual

Multi-Level BOM Structure Listing
Report No.:
Prepared by
020050[賴玉菁]
2004/12/03
Date
Page No.:
13
/
18
IEBO_P02
SEKAKU ELECTRON INDUSTRY (H.K.) CO.,LTD
Version UNIT:
PF01441
AMX-100FX
AMX-100FX_ALTO_230V
PCS
2003/12/17
Date:DESCRIPTION:
Item No.
Version Item No
Item Descri
Ver. UnitLoss %
Cardinal
@:Phantom Layer
Effective Date
Component Remark
Usage Rate
Attrition Rate
1.0000
1washer
φ7*φ12*0.5t
MF00060│├0041-------------------------------
││
0.00
%
││
PCS
2004/01/31
1.0000
1wire
90mm black L5R5
HA00373│├0042-------------------------------
││
0.00
%
││
PCS
2004/03/16
4.0000
1screw
M3*10
MG00166│├0043-------------------------------
││
0.00
%
││
PCS
2004/08/26
1.0000
1wire
35mm 黑 L5R12
HA02201│└0044-------------------------------
│
0.00
%
│
PCS
2004/09/16
│ P3-P4
│
1.0000
1PC board
P-FX-DSP-DIP
HK00832├0036---------------------------------
││
0.00
%
N
││
PCS
2003/12/24
1.0000
1row pin (single)#5100
2.0 90° 16P(gold-pated)2.5/9.5mm 2mm
HC00697│├0001-------------------------------
││
0.00
%
N
││
PCS
2004/10/14
││ CN1
││
1.0000
1PC board
P-FX-DSP-SMD
HK00833│└0002-------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
1.0000
1PCB
FX-DSP(1*10)_VER031014
HB01109│ ├0001------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
4.0000
1SMD ceramic capacitor 0603
22PF/50V NPO ±5%
CI00051│ ├0002------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ C329,C330,C331,C332
│ │
2.0000
1SMD ceramic capacitor 0603
33PF/50V NPO ±5%
CI00053│ ├0003------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ C348,C349
│ │
3.0000
1SMD ceramic capacitor 0603
0.0015uF/-50V X7R ±10%
CI00129│ ├0004------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ C345,C346,C347
│ │
8.0000
1SMD ceramic capacitor 0603
0.1uF/50V Y5V +80,-20%
CI00075│ ├0005------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ C333,C334,C336,C337,C338,C339,C340,C341
│ │
2.0000
1SMD tantalum capacitor
1.0uF/16V case A
CL00002│ ├0006------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ C352,C353
│ │
2.0000
1SMD tantalum capacitor
10uF/16V case B2
CL00006│ ├0007------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ C350,C351
│ │
2.0000
1SMD fixed resistor 1/10W
100Ω ±5% 0603
RD00068│ ├0008------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R420,R421
│ │
