Alto AMX-100 Service Manual

Multi-Level BOM Structure Listing
Report No.:
Prepared by
020050[賴玉菁]
2004/12/03
Date
Page No.:
14
/
18
IEBO_P02
SEKAKU ELECTRON INDUSTRY (H.K.) CO.,LTD
Version UNIT:
PF01441
AMX-100FX
AMX-100FX_ALTO_230V
PCS
2003/12/17
Date:DESCRIPTION:
Item No.
Version Item No
Item Descri
Ver. UnitLoss %
Cardinal
@:Phantom Layer
Effective Date
Component Remark
Usage Rate
Attrition Rate
1.0000
1SMD fixed resistor 1/10W
220Ω ±5% 0603
RD00073│ ├0009------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R426
│ │
1.0000
1SMD fixed resistor 1/10W
1.0KΩ ±5% 0603
RD00083│ ├0010------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R418
│ │
1.0000
1SMD fixed resistor 1/10W
2.2KΩ ±5% 0603
RD00088│ ├0011------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R424
│ │
2.0000
1SMD fixed resistor 1/10W
3.3KΩ ±5% 0603
RD00091│ ├0012------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R422,R423
│ │
1.0000
1SMD fixed resistor 1/10W
4.7KΩ ±5% 0603
RD00093│ ├0013------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R416
│ │
1.0000
1SMD fixed resistor 1/10W
7.5KΩ ±5% 0603
RD00098│ ├0014------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R419
│ │
18.0000
1SMD fixed resistor 1/10W
10KΩ ±5% 0603
RD00101│ ├0015------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R397,R398,R399,R400,R401,R402,R403,R404,R405,R406,
│ │ R407,R408,R409,R410,R411,R412,R413,R414
│ │
1.0000
1SMD fixed resistor 1/10W
47KΩ ±5% 0603
RD00111│ ├0016------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R415
│ │
1.0000
1SMD fixed resistor 1/10W
820KΩ ±5% 0603
RD00124│ ├0017------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R431
│ │
1.0000
1SMD fixed resistor 1/10W
1.0MΩ ±5% 0603
RD00125│ ├0018------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R417
│ │
1.0000
1SMD fixed resistor 1/10W
2.2MΩ ±5% 0603
RD00126│ ├0019------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ R425
│ │
3.0000
1SMD integrated circuit
NJM4580M-TE3
SG00122│ ├0020------------------------------
│ │
0.00
%
N
│ │
PCS
2003/12/16
│ │ U44,U45,U46
│ │

Alto AMX-100 Specifications

General

Brand	Alto
Model	AMX-100
Category	Music Mixer
Language	English
