SPECIFICATIONS
POWER SPECIFICATIONS
• Continuous power @ 0.5% THD: 4 Ohms 390W*2
• Both channels driven: 8 Ohms 250W*2
• Power EIAJ@ 1% THD 4 Ohms 500W*2
• Both channels driven: 8 Ohms 270W*2
• Bridge Mono Mode: 8 Ohms 1000W*1
20Hz-20kHz 16 Ohms 520W*1
ELECTRICAL SPECIFICATION
• INPUT SENSITIVITY: 1.0V
• INPUT IMPEDANCE: 10 K ohm unbalanced
• FREQUENCY RESPONSE: (at 10dB below rated output power) 20 Hz~25
KHz (+0/-3 dB)
• VOLTAGE GAIN: 32 dB
• DISTORTION: (SMPTE-1M) <0.5%
• S/N ratio: ＞110 dB
• Inrush Current at initial switch on: 5.85A
• Inrush Current after power supply interruption: 6.95A
GENERAL SPECIFICATIONS
• PROTECTIONS: ON/OFF, muting, DC-fault load grounding relay. Internal
fault fuses
• CONTROLS Front: AC switch
• CONTROLS Rear: Low pass filter, mode selector
• SIGNAL INDICATORS: 2 green LED CLIP: 2 red LED
• POWER INDICATORS: 1 Blue LED PROTECTION: 1 red LED
• INPUT CONNECTORS: Balanced combo
• OUTPUT: "Touch-proof" binding posts and speak-on jacks
DIMENSIONS
• (WxLxH) 483mm x 285mm x 88.8mm; 19” x 11.2” x 3.5”
WEIGHT
• 12.1 lb; 5.4kg
