Alto D1 - Rear Panel Controls; CIRCUIT BREAKER; IEC Socket for AC Power Cable; COMBO BALANCED INPUT CONNECTORS

BRIDGE MODE
HOOK
UP
The stereo or mono signal input to CH A and CH B is combined on the BRIDGE
MONO connector. Only CH A Gain control is active. The power at the output will
be combined power of the two channels.
ThisapplicationisonlyforD1orD3.FortheD2orD4,ithasfourchannelssoonly
use one amplifier. The Main Mix signal is routed into an electronic crossover. CH A drives
the woofer and CH B drives the high frequency driver in a 2-way enclosure.
STEREO BIAMP
HOOK
UP
