FX MUTE
PEAK
PRESETS
1
2
3
4
5
6
7
8
9
10
11
12
13
15
16
1. LARGE HALL
9
23 MAIN/CD/TAPE
22 AUX RETURNS
28
29
24 CD/TAPE TO MAIN MIX
If you push down the CD/TAPE TO MAIN MIX button, the CD/TAPE IN signal will be
routed into the MAIN output and will be adjusted by the MAIN MIX LEVEL knob.
27 POWER LED
This LED indicates when your is switched on.LYNX-MIX62(FX)
26 PHANTOM LED
This LED indicates when the PHANTOM POWER is engaged.
28 PRESETS
Adjust this control to select the desired effect.
There are a total of 16 Factory presets available
including WARM HALL, REV+DELAY, REV+CHORUS,
etc.
25 PHANTOM PWR Switch
This button will apply +48 Volt Phantom Power only to the 2 XLR MIC input
sockets. When condenser microphones are not used, please make sure that
the Phantom Power is disengaged.
DSP SECTION(For LYNX-MIX62FX Model)
If you push down the CD/TAPE TO CONTROL ROOM button, the CD/TAPE IN
signal will be routed into the Control Room output and the level will be adjusted
by the Control Room knob nearby the Main MIX LEVEL knob.
SPOTLIGHT
4. CONTROL ELEMENTS
TO MAIN MIX, This control is used to control the volume of the processed
signal sent to Main Mix bus, which can be varied from - to+10 dB.
TO AUX1 MON, This control is used to control the volume of the processed
signal sent to Monitor Mix, which can be varied from - to +10 dB.
There is a powerful 24-bit/16 preset digital multi-effects included in your
Effects include reverbs, chorus, flanger, delay and combinations of the
above.
LY N X -
MIX62FX
