3
2. Specification
MISTRAL900 MISTRAL1500
Output Power
20Hz~20KHz @0.1% THD, SCD MODE
8 ohms per channel (EIAJ) 190W 300W
4 ohms per channel (EIAJ) 300W 500W
BRIDGE MONO MODE
8 ohms , 1KHz, 0.1%THD 1400W 2000W
Distortion (SMPTE-IM)
<0.05%
Frequency Response 20Hz-20kHz +/- 0.1dB, -3 dB points: 10Hz-60kHz
Damping Factor, 1 kHz and below >300 at 8 ohms
Signal to Noise, 20 Hz-20 kHz 102 dB
VOLTAGE GAIN 40x (32dB)
Input Sensitivity @ 4 ohms 1Vrms
Input Clipping 10 Vrms (+22 dB)
Input Impedance 10 k ohms unbalanced, 20 k ohms balanced 56(36dB)
Controls
FRONT: AC SWITCH, CH1 & CH2 GAIN KNOBS
REAR: LIMITER, BRIDGE SELECTOR.
Indicators (1 per channel)
Power-On: Blue LED
Operation/Protection : Dual Color (Green/Red LED)
Limit : Red LED
Clip : Red LED
Connectors, each channel
Input: Active balanced XLR
Parallel Output : XLR
Output: NEUTRIK Speakon and Binding posts
Cooling Continuously variable-speed fan, rear-to-front air flow
Load Protection On/off muting, DC-fault load grounding relay. Internal fault fuses.
Power Requirements 200-240(100-120)Vac 50-60Hz
Dimensions
15.9" (40 cm) deep (rack mounting to rear support ears)
19" (48.3 cm) rack mounting, 3.5" (8.9 cm) tall (2 rack spaces)
