AL175UL Installation Guide - 5 -
Fig. 1 - AL175UL
AC
AL175ULB
DC
Stand-by
Battery
(optional)
Constant output
(Not affected
by trigger)
Switched
DC output
(trigger control)
SW1 ON - 24V
OFF - 12V
SW1
VR1
ON
NC NO C TRG1 TRG2
NC NO C
LOCK + STRIKE + COM -- AUX + FACP AUX --
+ BAT -- AC AC
Input 115VAC
60Hz, 0.6A
Black
Lead
White
Lead
Green Lead
(ground)
