Altronix AL400ULACMCB - Specifications

-
2
- ACMCBseries
Overview:
T
hese units distribute and switch power to access control systems and accessories. They convert a 115VAC 60Hz input
i
nto eight (8) independently controlled 12VDC or 24VDC PTC protected outputs. Outputs are activated by an open col-
l
ector sink or normally open (NO) dry trigger input from an Access Control System, Card Reader, Keypad, Push Button,
PIR, etc. Units will route power to a variety of access control hardware devices including: Mag Locks, Electric Strikes,
Magnetic Door Holders, etc. Outputs will operate in both Fail-Safe and/or Fail-Secure modes. The FACP Interface
enables Emergency Egress, Alarm Monitoring, or may be used to trigger other auxiliary devices. The fire alarm discon-
nect feature is individually selectable for any or all of the eight (8) outputs.
ACMCB Series Configuration Reference Chart:
AL400ULACMCB 4 3 8 Yes 1.9 amp 3.5A / 250V
AL600ULACMCB 6 6 8 Yes 1.9 amp 3.5A / 250V
AL1012ULA
CMCB 10 --- 8 Yes 1.9 amp 3.5A / 250V
AL1024ULACMCB --- 10 8 Yes 4.4 amp 10A / 250V
Specifications:
• Power suppl
y input options:
a) One (1) common power input for ACM8CB and lock power (factory installed).
b) Two (2) isolated power inputs (external power supply is required).
(current is determined b
y the power suppl
y connected, not to exceed a maximum of 10 amp total).
• Eight (8)
Access Control System trigger inputs.
Input options:
a)
Eight (8) normally open (NO) inputs.
b)
Eight (8) open collector inputs.
c) Any combination of the above.
• Eight (8) independently controlled Fail-Safe and/or Fail-Secure power outputs.
• Eight (8) auxiliary power outputs (unswitched) (PTC protected outputs are rated 2.5 amp).
• ACM8CB board main fuse is rated at 10 amp.
• Red LEDs indicate outputs are triggered (relays energized).
• Fire Alarm disconnect (latching or non-latching) is individually selectable for any or all of the eight (8) outputs.
F
ire
Alar
m disconnect input options:
a) Normally open (NO) or normally closed (NC) dry contact input.
b) Polarity reversal input from FACP signaling circuit..
•
Alarm output relay indicates that FACP input is triggered
(form “C” contact rated @ 1 amp 28VDC not evaluated by UL).
• Green LED indicates when FACP disconnect is triggered.
• Filtered and electronically regulated outputs (built-in power supply).
•
Built-in charger for sealed lead acid or gel type batteries.
•
AL400ULXB
, AL600ULXB and AL1012ULXB (Power Supply Board) maximum charge current .7 amp.
AL1024ULXB (P
o
w
er Suppl
y Board) maximum charge current 3.6 amp.
• Automatic switch over to stand-by battery when AC fails.
• Zero voltage drop when unit switches over to battery backup (AC failure condition).
• Thermal and short circuit protection with auto reset.
• AC input and DC output LED indicators.
• AC fail supervision (form "C" contact).
Altronix
Model Number
115VAC 60Hz Input
(current draw)
12VDC Total Output
Current (amp)
24VDC Total Output
Current (amp)
Outputs
Class 2 Rated
Po
wer Limited
Agency Listings
UL Listings and
File Numbers
Power Supply Board
Input Fuse Rating
UL File # BP6714
UL Listed for Access Control
System Units (UL 294).
“Signal Equipment”
Evaluated to
CSA Standard C22.2
No.205-M1983
