Page #7 background imageLoading...
Page #7 background image
Terminal Identification Tables:
Power Supply Board
Terminal Legend Function/Description
L, N Connect 115VAC 60Hz to these terminals: L to hot, N to neutral.
+ DC –
AL400ULACM - 12VDC @ 4 amp or 24VDC @ 3 amp to ACM8 board (power-limited).
AL600ULACM - 12VDC/24VDC @ 6 amp to ACM8 board (non power-limited).
AL1012ULACM - 12VDC @ 10 amp to ACM8 board (non power-limited).
AL1024ULACM - 24VDC @ 10 amp to ACM8 board (non power-limited).
AC FAIL
NC, C, NO
Used to notify loss of AC power, e.g. connect to audible device or alarm panel. Relay normally
energized when AC power is present. Contact rating 1 amp @ 28VDC. AC or brownout fail is
reported within 1 minute of event. To delay reporting of up to 6 hrs. cut “AC delay” jumper and
reset power to unit.
BAT FAIL
NC, C, NO
Used to indicate low battery condition, e.g. connect to alarm panel. Relay normally energized when
DC power is present. Contact rating 1 amp @ 28VDC. A removed battery is reported within 5 min-
utes. Battery reconnection is reported within 1 minute.
Low battery threshold:
12VDC output threshold set @ approximately 10.5VDC (N/A for AL1024ULACM),
24VDC output threshold set @ approximately 21VDC (N/A for AL1012ULACM).
+ BAT –
Stand-by battery connections. AL400ULXB2, AL600ULXB and AL1012ULXB
(Power Supply Board) maximum charge current is 0.7 amp. AL1024ULXB2
(Power Supply Board) maximum charge current is 3.6 amp.
ACM8 Access Power Controller
Terminal Legend Function/Description
– Power + 12VDC or 24VDC input from power supply board.
– Control +
These terminals can be connected to a separate power-limited UL Listed power supply to
provide isolated operating power for the ACM8 (jumpers J1and J2 Must be removed).
TRIGGER
INPUT 1 - INPUT 8
IN, GND
From normally open and/or open collector sink trigger inputs
(request to exit buttons, exit pir’s, etc.).
OUTPUT 1 -
OUTPUT 8
NC, C, NO, COM
12 to 24 volts AC/DC trigger controlled outputs:
Fail-Safe [NC positive (+) & COM Negative (-)],
Fail-Secure [NO positive (+) & COM Negative (-)],
Auxiliary output [C positive (+) & COM Negative (-)]
(When using AC power supplies polarity need not be observed),
NC, C, NO become form “C” 5 amp 24VAC/VDC rated dry outputs when fuses are removed.
Contacts shown in a non-triggered state.
FACP INTERFACE
T, + INPUT
Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
normally closed from an FACP output circuit (Fig. 4 through 8, pg. 8).
FACP INTERFACE
NC, C, NO
Form “C” relay contact rated @ 1 amp 28VDC for alarm reporting.
(This output has not been evaluated by UL).
ACM series - 7 -
