Altronix AL600ULACM User Manual

- DC +
L G N
+ BAT -
AC FAIL
BAT FAIL
Battery and AC
Supervision Circuit
(power-limited)
Green
Flying
Lead
Door
Wire
Strap
(from
Enclosure
to Door)
DC Output to devices (power-limited for AL400ULACM,
non power-limited for all other models*)
Fire
Alarm
Interface
Insulating
Barrier
Inputs (power-limited)
unswitched
115VAC
power mains
(non power-limited)
Power Supply Board
CAUTION: De-energize unit prior to servicing.
For continued protection against fire hazard replace
fuse with the same type and rating.
*When class 2 rating is required order model numbers:
Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing.
Observe
polarity
SW1
AC DELAY
CAUTION: Optional rechargeable stand-by batteries must match
the power supply output voltage setting.
Optional Rechargeable
Stand-by Battery
Optional Rechargeable
Stand-by Battery
OFF --- 24V
ON --- 12V
ON
NC C NO COM
OUTPUT 1
LED1
F1
NC C NO COM
OUTPUT 2
IN GND
1
IN GND
2
IN GND
3
IN GND
4
IN GND
5
IN GND
6
IN GND
7
MAIN
IN GND
8
LED2
LED3
LED4
LED5
LED6
LED7
LED8
J2
J3
J1
TRG
NC C NO COM
OUTPUT 3
NC C NO COM
OUTPUT 4
NC C NO COM
OUTPUT 5
NC C NO COM
OUTPUT 6
NO C NC + INP --- T + RET -
NC C NO COM
OUTPUT 7
NC C NO COM
OUTPUT 8
--- +
Power
--- +
Control
F2
F3
F6 F7 F8
F4
F5
3.5A 250V 3.5A 250V 3.5A 250V3.5A 250V 3.5A 250V3.5A 250V3.5A 250V 3.5A 250V
FACP INTERFACE
10A 250V
1 2 3 4
ON
1 2 3 4
ON
Fig. 2
AL400ULACMCB, AL600ULACMCB, AL1012ULACMCB and AL1024ULACMCB
- 6 - ACM series
