Input:
• Power input 115VAC, 60Hz (see reference chart above).
• Fire Alarm Panel or Access Control System trigger inputs.
[NO] or [NC] supervised trigger input and
polarity reversal trigger input (4mA draw from FACP).
Output:
• Five (5) individual power-limited Class 2 outputs
(auto-resettable).
• Current limit is 2A @ 12VDC or 24VDC per output
(12VDC only for AL1012ULM, 24VDC only for AL1024ULM).
Burglar Alarm Applications (UL 603)
(AL300ULM and AL400ULM only):
12VDC = 10VDC-13.2VDC.
24VDC = 20VDC-26.4VDC.
• Filtered and electronically regulated outputs.
• Thermal and short circuit protection with auto reset.
• Overload protection.
• Output relay energizes when unit is triggered
(form “C” contact rated 1A @ 28VDC).
Visual Indicators:
• DC output LED indicator.
• LEDs indicate condition of power outputs.
• Power and input trigger LEDs.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switch over to stand-by battery when AC fails.
• Zero voltage drop when switching over to battery backup.
• AL300ULM, AL400ULM, AL600ULM, and AL1012ULM
(Power Supply Board) maximum charge current 0.7A.
AL1024ULM (Power Supply Board) maximum
charge current 3.6A.
• AL300ULM, AL400ULM, and AL600ULM enclosures
accommodate up to two (2) 12VDC/7AH batteries.
• AL1012ULM should be fitted with
one (1) 12VDC/12AH battery.
• AL1024ULM should be fitted with
two (2) 12VDC/12AH batteries.
Supervision:
• AC fail supervision (form “C” contact).
• Low battery supervision (form “C” contact).
• Battery presence supervision (form “C” contact).
• Power fail supervision relay
(form “C” contact rated 1A @ 28VDC).
Additional Features:
• Power supply is complete with enclosure, cam lock,
and battery leads.
Overview:
Altronix M Series multi-output access control power supply/chargers are specifically designed for use with access control systems and
accessories. These units convert a 115VAC, 60Hz input into five (5) individually protected 12VDC or 24VDC outputs (see specifica-
tions). Each output will route power to a variety of access control hardware devices including Mag Locks, Electric Strikes, Magnetic Door
Holders, etc. These outputs will operate in both Fail-Safe and Fail-Secure modes. Controlled trigger input is achieved through normally
open [NO] or normally closed [NC] supervised input or the polarity reversal from an FACP (Fire Alarm Control Panel). A form “C” dry
output relay enables HVAC Shutdown, Elevator Recall or may be used to trigger auxiliary devices.
M Series Power Supply Configuration Reference Chart:
Altronix
Model
Number
12VDC Total
Output Current (A)
24VDC Total
Output Current (A)
PTC Protected
Outputs
(Auto-resettable)
Class 2 Rated
Power-Limited
115VAC, 60Hz Input
(current draw/A)
Power Supply Board
Input Fuse Rating
Power Supply Board
Output Fuse Rating
Agency Listings
UL Listings and
File Numbers
AL300ULM
2.5 2.5
5 Yes
3.5A
5A/
250V
15A/
32V
UL 1481 - UL Listed for Power Supplies for
Fire Protective Signaling Systems
UL 294 - UL Listed Access Control System Unit.
UL 603 - UL Listed for Burglar Alarms Systems.
UL 1069 - UL Listed Hospital Signaling and
Nurse Call Equipment.
---------------------------------
“Signal Equipment” Evaluated to CSA 22.2 N205-M1983
AL400ULM
4 3 3.5A
5A/
250V
15A/
32V
AL600ULM
6 6 3.5A
5A/
250V
-------------
AL1012ULM
10 ------------- 2.6A
5A/
250V
15A/
32V
UL File # BP617
UL 294 - UL Listed Access Control System Unit.
---------------------------------
“Signal Equipment” Evaluated to CSA 22.2 N205-M1983
AL1024ULM
------------- 10 4.2A
5A/
250V
15A/
32V
UL 1481 - UL Listed for Power Supplies for
Fire Protective Signaling Systems
UL 294 - UL Listed Access Control System Unit.
---------------------------------
“Signal Equipment” Evaluated to CSA 22.2 N205-M1983
Specifications:
California State Fire Marshal
NYC Dept. of Buildings
140 58th St. Brooklyn, NY
California State Fire Marshal
NYC Dept. of Buildings
140 58th St. Brooklyn, NY
To Next Page
