IPB-5000B
10. External Communication Function
10-1
10. External Communication Function
(1) Introduction
IPB-5000B can be used to set schedules from an externally-connected personal
computer (abbreviated as PC) or to read monitored data and several kinds of status
data.
(2) Data Transmission
Item Content
Transmission Mode
Select either of the followings at STATUS Screen:
* RS-485, Asynchronous, Half-Duplex
* RS-232C
Transmission Rate
Select either of the followings at STATUS Screen:
9600, 19200, 38400 bps
Data Format Start bit: 1, Data bit: 8, Stop bit: 1, Parity bit: Even
Character Code
Output in ASCII code
LF Code: [LF] 0AH, Space Code: [SP] 32H
CR Code: [CR] 0DH
Checksum Data None
Connector
D-Sub 9 pins
Pin Position
In RS-485, 5: SG, 6: RS+, 9: RS-
In RS-232C, 2: RXD, 3: TXD, 5: SG
