IPB-5000B
10. External Communication Function
10-6
No. Description of Command Code
5
Setting of Specified Data
# Device No. W Schedule No.
Specified Code : Data
Example: Set the current of 1st. Weld Time on Schedule No. 31 in
Device No. 01 to 3.2 kA.
From Host PC to IPB-5000B
# ID1 ID2 W SH1 SH2 SH3 CD1 CD2 CD3 : Data CR LF
(# 0 1 W 0 3 1 H 0 1 : 3 . 2 0 k A CR LF)
From IPB-5000B to Host PC
! ID1 ID2 SH1 SH2 SH3 : Data CR LF
(! 0 1 0 3 1 H 0 1 : 3 . 2 0 k A CR LF)
Note) * See (5)Specified Code for Specified Code and Data.
* Regarding the number of digits and location of the decimal
point in each data, each data is required to follow Data
Code Table.
* The set data is returned as confirmation from IPB-5000B.
When data outside the range is set, the last data before
setting is exactly returned.
6
Reading of Initial Setting # Device No. R Specified Code
Example: Read model of Transformer IT*-360*6 (Data is 01) at Initial
Setting (6.(9) STATUS Screen) in Device No. 01.
From Host PC to IPB-5000B
# ID1 ID2 R CD1 CD2 CD3 CR LF
(# 0 1 R P 4 0 CR LF)
From IPB-5000B to Host PC
! ID1 ID2 CD1 CD2 CD3 : Data CR LF
(! 0 1 P 4 0 : 0 1 CR LF)
Note) See (5)Specified Code for Specified Code and Data.
7
Setting of Initial Setting
Condition
# Device No. W Specified Code : Data
Example: Set the time period during which Weld End Signal Time is
output to 100 ms (Data is 01) at Initial Setting (6.(9)
STATUS Screen) in Device No. 01.
From Host PC to IPB-5000B
# ID1 ID2 W CD1 CD2 CD3 : Data CR LF
(# 0 1 W P 0 3 : 0 1 CR LF)
From IPB-5000B to Host PC
! ID1 ID2 CD1 CD2 CD3 : Data CR LF
(! 0 1 P 0 3 : 0 1 CR LF)
Note) * See (5)Specified Code for Specified Code and Data.
* Regarding the number of digits and location of the decimal
point in each data, each data is required to follow Data
Code Table.
* The set data is returned as confirmation from IPB-5000B.
When data outside the range is set, the last data before
setting is exactly returned.
To Next Page
