10. External Communication Function
10-15
Order
Output Data
(n=0 to 9)
Contents
9 n.nn, Precheck Monitor Current
10 n.nn, WE1 Monitor Current (RMS Value)
11 n.nn, WE2 Monitor Current (RMS Value)
12 n.nn, WE1 Monitor Voltage (RMS Value)
13 n.nn, WE2 Monitor Voltage (RMS Value)
14 ±nn.nnn, Final Displacement
15 nnn.n, WE1 Weld Time
16 nnn.n, WE2 Weld Time
17 ±nn.nnn Work Detecting Displacement
NB1: The range between 0.0 and 9.9 is output as [SP]0.0 and [SP]9.9.
6) Reading of Items relating with Envelope (V)
Specified
Code
Item Contents
V00 Envelope Type
0: Current, 1: Voltage, 2: Power,
3: Resistance, 4: Displacement
V01 Interval Start Time nnnnnms
V02 Interval End Time nnnnnms
V03 Offset Upper Limit (+)
n.nnkA/n.nnV/nn.nkW/nn.nm*/
nn.nnnmm
(NB1)
V04 Offset Lower Limit (-)
n.nnkA/n.nnV/nn.nkW/nn.nm*/
nn.nnnmm
(NB1)
V05 Envelope ON/OFF
0：OFF, 1：ON
NB1: The symbol “*” means Ω.
7) Setting of Items relating with Counter (C)
Specified
Code
Item Contents
C00 Reading of Displayed Counter
C14 Counter Mode 0: TOTAL, 1: GOOD, 2: WORK
C05 Preset (TOTAL/GOOD) 000000 to 999999
C06 Preset (WORK) 000000 to 999999
C07 Preset (WELD) 00 to 99
C11 Counter Reset (All Counters)
C12
Resolution of Displacement
Sensor
00.1 to 10.0um
